KV Cache

Why KV Cache exists

During generation, the model repeatedly attends to previous tokens. KV Cache saves the Key and Value representations of those tokens so they can be reused instead of recomputed at every step, making generation faster while using more GPU memory.

Tradeoff is simple: fast computation with more GPU memory

How autoregressive generation works without KV Cache

An LLM generates text one token at a time.

For example model might generate:

The cat → is
The cat is → sitting
The cat is sitting → on
The cat is sitting on → the

Without KV Cache, the model repeatedly processes the entire sequence at every generation step.

For example, when generating sitting:

The → Q₁ K₁ V₁
cat → Q₂ K₂ V₂
is  → Q₃ K₃ V₃

The model performs attention over these representations and predicts sitting.

When generating the next token, on, it processes everything again:

The     → Q₁ K₁ V₁   ← recalculated
cat     → Q₂ K₂ V₂   ← recalculated
is      → Q₃ K₃ V₃   ← recalculated
sitting → Q₄ K₄ V₄   ← new

The important observation is that the K and V representations of previous tokens haven’t changed. Yet, without a cache, they are calculated again at every generation step.

This is where KV Cache comes in: instead of throwing away the K and V representations after each step, the model stores them and reuses them when generating the next token.

The key difference

without KV Cache

Without KV Cache, each step recomputes everything: [The, cat], then [The, cat, is], then [The, cat, is, sitting], recomputing all tokens again each time

with KV Cache

With KV Cache, the first input computes and caches K/V, then each new token (is, sitting) computes only its own K/V and adds it to the cache

Common KV Cache Trade-offs

KV Cache grows with the number of tokens being generated.

More tokens
    ↓
More K/V vectors
    ↓
Larger KV Cache
    ↓
More GPU memory

This becomes especially important when serving multiple requests simultaneously.

Paged KV Cache / PagedAttention

A basic KV Cache can become inefficient when an inference server is handling many requests with different sequence lengths.

PagedAttention, introduced by the vLLM project, applies an idea similar to virtual memory in operating systems.

Instead of requiring each request’s KV Cache to occupy one large contiguous region, the cache is divided into smaller blocks/pages.

KV Cache

Request A → [Block 1] [Block 7] [Block 12]
Request B → [Block 2] [Block 4]
Request C → [Block 3] [Block 8] [Block 15]

The blocks don’t have to sit next to each other in GPU memory.

A mapping keeps track of where each block belongs.

This allows the inference engine to use GPU memory more efficiently and makes it easier to dynamically allocate and manage KV Cache across many requests.

Why it matters

PagedAttention is particularly useful for LLM serving, where the goal isn’t just to make one request fast.

The system needs to efficiently handle:

Many users
   ↓
Many concurrent sequences
   ↓
Many KV Caches
   ↓
Limited GPU memory

So PagedAttention is primarily a memory-management technique for KV Cache, rather than a change to the underlying attention mechanism.

KV Cache Eviction / Compression

KV Cache grows as the sequence gets longer.

Eventually, the cache can become too large for the available GPU memory.

So another question arises:

Do we really need to keep every cached token?

Not necessarily.

Some techniques attempt to remove, compress, or otherwise reduce the amount of KV Cache that needs to remain in memory.

The basic idea is:

Large KV Cache
      ↓
Identify less useful tokens
      ↓
Remove some K/V entries
      ↓
Smaller KV Cache

KV Cache Compression

Instead of completely removing information, compression techniques try to represent the cache using less memory.

Different approaches can reduce memory through techniques such as:

storing K/V representations at lower precision (Quantized KV)
reducing the number of stored K/V vectors
selectively retaining important tokens
sharing or grouping K/V representations

Reduce KV Cache memory while keeping the impact on generation quality as small as possible.

KV Cache management flow: evaluate the trade-off of faster decoding versus more GPU memory, implement PagedAttention to manage that memory, then apply eviction or compression to reduce how much is needed

Multi-Head Attention and KV Cache

Multi-Head Attention (MHA) uses multiple attention heads, where each head has its own Q, K, and V projections.

During autoregressive generation, the K and V from previous tokens are stored in the KV Cache so they don’t need to be recomputed.

More attention heads → more K/V data → larger KV Cache.

MHA vs MQA vs GQA

The main difference is how K/V heads are shared across Query heads:

Comparison table: MHA has many query heads and the same number of KV heads, giving the largest KV Cache; GQA has fewer grouped KV heads, giving a smaller cache; MQA has a single KV head, giving the smallest cache

GQA and MQA reduce KV Cache memory by sharing K/V across multiple Query heads.
